Name: TS 230 SDI climate sensor | Free Shipping
Price: 6049.45 AED
Availability: InStock

TS 230 SDI climate sensor

Here are some technical details of the TS 230 SDI

Display Sensor 1: Temperature

Measuring range temperature: -40.0 °C … +140.0 °C, briefly up to +180°C

Resolution temperature: 0.1°C

Accuracy temperature: ±0.2 °C at 20 °C, ±0.7 °C at -40 °C to +140 °C

Units (Unit 1) for display sensor 1: °C, °F

Display sensor 2: relative humidity, absolute humidity, mixing ratio, dew point

Measuring range rel. humidity: 0.0 … 100.0 % r.h.

Resolution rel. humidity: 0.1 % r.h.

Accuracy rel. humidity: ± 2% at 0…90.0% r.H. ; ± 3 % at 90.0….100.0% r.H.

Units (Unit 2) for display sensor 2: % r.h., dp °C, dp °F, g / m³, g/kg

Sensor element

Material: stainless steel

Length / Ø: 250 mm / 12 mm

Sensor handle Ambient conditions: 0 °C to +50 °C (measuring electronics in handle)

This sensor TS 230 SDI is connected using the TC 30 SDI connection cable!

Description

Technical data

Master Data
SKU	3510220220
Length without packaging [mm]	250 mm
Weight without packaging [kg]	0.2 kg
Diameter without packaging [mm]	12 mm
Appearance
Handle material	Plastics
Functions and features
Stainless steel probe
Internal sensors
Absolute humidity content [g/m³]
Air temperature [°C]
Air temperature [°F]
Dew point temperature [°C]
Dew point temperature [°F]
Relative humidity [%]
Interfaces/connector format
SDI connector
Material design of sensor element
Stainless steel
accuracy_relative_humidity
Humidity level	Accuracy [%]
0 -90 % RH	2
	3

All climate values visible at a glance – precise and in real time

The TS 230 SDI climate sensor displays temperature and humidity values simultaneously in real time on the multifunction measuring device. In addition to the current measured values, optional display modes such as minimum, maximum, average and hold can be selected, ensuring maximum transparency, control and reliability for professional climate measurements and documentation.
